Product Details:
Payment & Shipping Terms:
|
Feature: | High Efficiency | Color: | Customer's Request |
---|---|---|---|
CertifiPCion: | ISO9001:2008 | Keyword: | Excavator Magnet Lift |
AppliPCion: | Farms, Home Use, Energy & Mining, Construction Works | Suitable: | 1-50t Excavator |
Service: | OEM & Customized | Pins: | Heat Treatment |
High Light: | Excavator Energy Forest Timber Wood Grapple,360 Degree Rotating Wood Grapple,50T Excavator Wood Grapple |
Item
|
Unit
|
HT-02
|
HT-04
|
HT-06
|
HT-08
|
HT-10
|
---|---|---|---|---|---|---|
AppliPCion Excavator
|
tons
|
1.5-3
|
4-9
|
10-18
|
20-30
|
31-45
|
Weight
|
kg
|
280
|
380
|
750
|
1500
|
1800
|
Max jaw opening
|
mm
|
1200
|
1400
|
1600
|
1800
|
2000
|
Height
|
mm
|
1000
|
1200
|
1500
|
1700
|
1900
|
Wide
|
mm
|
350
|
450
|
600
|
800
|
900
|
Cylinder Volume
|
tons
|
4.0*2
|
4.5*2
|
8.0*2
|
10*2
|
12*2
|
This specifiPCions are subject to change without prior notice for the improvement of quality.
The company has been developed to meet with the high standards of the current market.
The demand for high durability and low maintenance costs on hydraulic equipment are combined in the total design of our quick couplers.
(1). Unlimited clockwise and anti-clockwise 360° rotatable swing bearing system
(2). Equipped with German-made M+S motor, more powerful and stable
(3). Using handles to operate the grapple which is more comfortable and flexible for driver
(4). Original German oil seals, balance valve, safety valve making cylinder more durable and safe
(5). Brake valve making it safer from inertia or accidents
Product Advantages
1. Material:
1) Entire jaw structure is manufactured of quenched and tempered Q690 High Strength alloy steel, 130,000-psi min. yield 360-440BHN.
2) The tine tips are 175,000-psi min. yield 450-550 BHN. Chromium plating.
2.Motor:
1) Motor drive adopts the design of symmetrical double support,strong shcok resistance, avoiding axle breakage and oil leakage.
2) Pedestal adopts sealed type design, better protect the rotary drive.
3) Output Torque:4 kN.m-8.5kN.m(6272lbf.ft)
Holding Torque 38kN.m-105kN.m(78000lbf.ft)
Moment Torque 26kN.m-203kN.m(150,000lbf.ft)
3. Strengths:
1) Sealed type rotary drive solve the oil leakage problem, only required light greasing(80g of grease) once 6 months(unlike most
of the product on the market needed greasing everyday) and better protect the product.
2) Motor drive adopted symetrical double support design, reducing the bearing load and extend service life.
3) The jaw structure is manufactured of Q690 High Strength Alloy Steel, lighter weight with twice of the strength comparing with
Q345(normally used on the market)
1. Before signing an official contract with our customers, we will help to analyze and provide professional solutions, recommdations based on the project information provided by customers.
2. An experienced tech-team are ready to meet your special requirements.
3. Your inquire related to our products or price will be replied in 24 hrs
4. Keeping our customers update about the orders' production process and arrange quality checking in the workshop is available if you want.
5. Online techinical supports are available for the whole product life. Oversea services are available with extra fees.
1.Packing: standard export wooden pallet or export wooden cases
2.Delivery time:10-15 working days after receiving your advance payment
3. We have a team specialized into packing and loading container , they have rich experience, and we can load the max.quantity excavator buckets and parts, to help customers save ocean freight.
Carrier | 6-10T Excavator |
---|---|
Max jaw opening | 1200mm,1360mm, can be customized |
Operating Pressure | 18-22Mpa
|
Flow Rate | 35-40L/Min |
Weight | 330-380KG |
Snatch Weight | at least 1 Ton |
Color | Black,Blue,Yellow |
AppliPCion | Grab wood,Sugar cane,Bamboo,Stone,Big stuff etc. |
SPECIFIPCIONS FOR LG GRAPPLE
|
|
|||
---|---|---|---|---|
Model
|
Max Open (mm)
|
Grip Area (㎡)
|
Lift Capacity(kg)
|
Weight(kg)
|
HT012
|
800
|
0.12
|
550
|
50
|
HT013
|
800
|
0.12
|
550
|
50
|
HT016
|
1040
|
0.16
|
1000
|
70
|
HT017
|
1040
|
0.16
|
1000
|
86
|
HT018
|
1180
|
0.16
|
1000
|
65
|
HT019
|
1260
|
0.19
|
1500
|
100
|
HT020
|
1330
|
160L
|
1000
|
180
|
HT021
|
1260
|
0.19
|
1500
|
130
|
HT022
|
1305
|
0.22
|
2000
|
105
|
HT023
|
1275
|
0.24
|
2000
|
145
|
HT036
|
1620
|
0.36
|
2500
|
230
|
HT037
|
1620
|
0.36
|
2500
|
250
|
HT045
|
1960
|
0.45
|
3000
|
365
|
Q: Are you a manufacturer / factory?
A: Yes, we are the manufacturer and established in 2008.
Q: Do you accept OEM?
A: Yes, OEM & customized manufacturing are available. Please send us the drawings, we can produce the products as your request.
Q: Can I have some samples?
A: Of course, sample order is available. Lead time: 2-3 days. Customized samples: About 7-10 days.
