Excellent performance with high durability. The company has been developed to meet with the high standards of the current market. The demand for high durability and low maintenance costs on hydraulic equipment are combined in the total design of our rakes.
1. Before signing an official contract with our customers, we will help to analyze and provide professional solutions, recommdations based on the project information provided by customers.
2. An experienced tech-team are ready to meet your special requirements.
3. Your inquire related to our products or price will be replied in 24 hrs
4. Keeping our customers update about the orders' production process and arrange quality checking in the workshop is available if you want.
5. Online techinical supports are available for the whole product life. Oversea services are available with extra fees.
1.Packing:standard export wooden pallet or export wooden cases
2.Delivery time:10-15 working days after receiving your advance payment
3.We have a team specialized into packing and loading container,they have rich experience,and we can load the max.quantity excavator buckets and parts,to help customer save ocean freight.
| HT RAKE | |||
| Type | Material | CertifiPCion | AppliPCion |
| General-Purpose Rake | Q355/Q460 | ISO9001:2008 | Root Cleaning, Soil, Sand |
| Heaby-Duty-Rake | Q355/Q460/NM360 | Root, Soil, Sand, Gravel, Rock | |
| Severe-Duty-Rake | Q355/NM360/HARDOX500 | Root, Soil, Sand, Gravel, Rock, Metal, Construction Material | |
| Material Used | ||||||||||
| Material | Code | Related Chemical Composition | Hardness(HB) | Extension(%) | Drag and extension intensity (N/mm2) | Bend Intensity (N/mm2) | ||||
| C | Si | Mn | P | S | ||||||
| Alloy | Q355B | 0.18 | 0.55 | 1.4 | 0.03 | 0.03 | 163-187 | 21 | 470-660 | 355 |
| Chinese High-Strength alloy | NM360 | 0.2 | 0.3 | 1.3 | 0.02 | 0.006 | 360 | 16 | 1200 | 1020 |
| High-Strength alloy | HARDOX-500 | 0.2 | 0.7 | 1.7 | 0.025 | 0.01 | 470-500 | 8 | 1550 | 1300 |
