3-10 Tons Excavator Rotating Grapple / Hydraulic Grapple For Hitachi ZX100 ZX220
Production Description
Huiytong Excavator Stone Grapple ,Excavator Rock Grab is a kind of excavator attachments that is mainly used for stone, rock, steel, wood, log, timber, and other large scraps handing, moving, loading and organizing.The jaw structure is manufactured of Q690 High Strength Alloy Steel, lighter weight with twice of the strength comparing with Q345(normally used on the market)
They can be used to demolish buildings and handling all types of loose debris and lodged heavy material. They are adaptable to many industries including demolition, scrap and waste handling.
We can make products to fit for excavator brand: PC, Komatsu, Volvo, Kobelco, Daewoo, Hyundai, Hitachi, SANY, XCMG, ect.
Features
- Available with or without 360° Continuous Rotation.
- Non-rotation style can be mounted side-on or direct-on to the machine.
- Full Dual Cylinder Hydraulic Action.
- Shrouded hydraulic cylinders & hoses.
- Thru Hardened alloy master pin with heavy wall alloy bearings.
- Built-in bypass high pressure hydraulic protection.
- Removable Access Plates to Hydraulics
|
Huitong Grapple SpecifiPCions
|
HT- 100Z
|
|
|
Whole Grapple
|
Grapple Type
|
single cylinder/Five-Jaw grapple/doubble link
|
|
Steel material
|
Q355B
|
|
|
Optional electric control
|
✔
|
|
|
Height when clamped(mm)
|
1380
|
|
|
Height when opened(mm)
|
1360
|
|
|
Width of inner/outer clamp(mm)
|
415/700
|
|
|
Open Width Max(mm)
|
1250±20
|
|
|
Minimum holding circle(mm)
|
≦φ110
|
|
|
Maximum holding circle(mm)
|
φ500
|
|
|
Weight (excluding rotation)kg
|
380
|
|
|
Suitable Excavator(Ton)
|
5-9
|
|
|
|
Rotation method(grapple)
|
external meshing vertical rotation
|
|
Module / raceway diameter
|
M5/224
|
|
|
|
Motor type
|
Cycloid motor
|
|
Pressure(Mpa)
|
16
|
|
|
|
Rod diameter/bore size
|
45/80
|
|
Pressure(Mpa)
|
21
|
|
