Wheeled Excavator Grapple Attachment WX210 WX185 WX165 Q355b Excavators Rock Grapple

Name: Wheeled Excavator Grapple Attachment WX210 WX185 WX165 Q355b Excavators Rock Grapple
Brand: Huitong
SKU: Huitong
Price: 580 USD
Availability: InStock
Rating: 5 (127 reviews)

Large Image : Wheeled Excavator Grapple Attachment WX210 WX185 WX165 Q355b Excavators Rock Grapple

Product Details:

Place of Origin:	Guangzhou,China
Brand Name:	Huitong

Payment & Shipping Terms:

Minimum Order Quantity:	1 Pcs
Price:	$580-1000/pcs
Packaging Details:	standard package
Delivery Time:	7-10 workdays
Payment Terms:	D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	200 pcs per mounth

Contact Now

Detailed Product Description

Product Name:	Manual Grapple	Type:	Excavator Mechanical
Materials:	Q355b	AppliPCion:	Grabing Rocks, Wood, Crops
OEM Service:	Available	Warranty:	6 Months
High Light:	Wheeled Excavator Grapple Attachment WX210 , Q355b Excavators Rock Grapple , WX210 mechanical grab for excavator

Excavator Mechanical Grapple Q355b Rock Grapple For Excavator PC55 PC80 PC100

Prodution Descrition

Factory direct sale mini excavator timber grapple for PC30 pc50 pc60 log grapple

HT Mechanical Grapple is a lifting appliance which depends on jaw opening and closing crawl and unloading bulk material.

Excavator wood grapple has two jaws, left and right sides, two to five claws or even more, by working on both sides of the opening and closing to grab material, shaped like two forks, as named "Fork Excavator Grapple."

Features

1. Long Work Time:

a. Usingspecial steel material with high ductility and high abrasion resistance
b. The simpler structure, the lower failure rate
2. Excellent performance:
a. The widest open width in the same level.
b. The most excellent performance but the lightest weight.
3. Easy Operation:
Easy to be installed, drived by the excavator hydraulic system.

Huitong Excvator Model

model	Max openning	Weight	Carrier	Holdng area	Max pressure	Working flow	Holding power	Weight
model	Mm	Kg	Ton	M2	Bar	L/min	Kn	Kg
HT28	1690	416	10	0.3	300	60	16.2	416
HT42	1900	555	14	0.45	300	90	25	555
HT55	2270	1068	20	0.58	300	90	25	1068

Production Details
Wheeled Excavator Grapple Attachment WX210 WX185 WX165 Q355b Excavators Rock Grapple

Suitable Excavtor

PC20-7	PC30	PC30-3	PC30-5	PC30-6	PC40-7	PC45	PC45-2
PC120-6	PC130	PC130-7	PC200	PC200-1	PC200-3	PC200-5	PC200-6
PC200-8	PC210-6	PC220-1	PC220-3	PC220-6	PC220-7	PC220-8	PC270-7
PC220LC-6	PC220LC-8	PC240	PC300	PC300-3	PC300-5	PC300-6	PC300-7
PC300LC-7	PC350-6/7	PC400	PC400-3	PC400-5	PC400-6	PC400lc-7	PC450-6
EX40-1	EX40-2	EX55	EX60	EX60-2	EX60-3	EX60-5	EX70
EX100	EX110	EX120	EX120-1	EX120-2	EX120-3	EX120-5	EX130-1
EX200-2	EX200-3	EX200-5	EX220-3	EX220-5	EX270	EX300	EX300-1
EX300-3	EX300-5	EX300A	EX330	EX370	EX400-1	EX400-2	EX400-3
EX450	ZAX30	ZAX55	ZAX200	ZAX200-2	ZAX330	ZAX450-1	ZAX450-3
