Excavator Hydraulic Pile Hammer 165mm Impact Vibro Hammer

Excavator Hydraulic Pile Hammer 165mm Impact Vibro Hammer
Excavator Hydraulic Pile Hammer 165mm Impact Vibro Hammer
video play

Large Image :  Excavator Hydraulic Pile Hammer 165mm Impact Vibro Hammer

Product Details:
Place of Origin: China
Brand Name: HUITONG
Model Number: komatsu/hitachi/PC/hyundai/Volvo
Payment & Shipping Terms:
Minimum Order Quantity: 1 PCS/SET
Price: USD12000-18000/SET
Delivery Time: 7-15 work days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 200SET per month
Detailed Product Description
Product Name: Hydraulic Vibratory Hammer AppliPCion: Building Foundation,Pile Driving,
Condition: New Color: Blue Or Customer's Requirement
Weight: 1.3T MOQ: 1 SET
After-sales Service Provided: Online Support
High Light:

Excavator Hydraulic Pile Hammer

,

165mm Excavator Hydraulic Pile Hammer

Excavator Hydraulic Pile Hammer 165mm Excavator Hydraulic Impact Vibro Hammer

Excavator Hydraulic Pile Hammer 165mm Impact Vibro Hammer

Excavator Pile Hammer
Huitong Hydraulic Pile Hammers , also goes by Pile Driving Hammers, Vibro Hammers, which are widely used in many construction projects. It can be used for driving and extracting piles in different geological condition except for the hard rock layer. Hydraulic Pile Hammers usually work with our piling arm, appliPCons like used in trestle work, cofferdam,offshore working platform, and also wind mill single pile or group pile.

Excavator Hydraulic Pile Hammer 165mm Impact Vibro Hammer Excavator Hydraulic Pile Hammer 165mm Impact Vibro Hammer

Excavator Hydraulic Pile Hammer 165mm Impact Vibro Hammer Excavator Hydraulic Pile Hammer 165mm Impact Vibro Hammer Excavator Hydraulic Pile Hammer 165mm Impact Vibro Hammer

Excavator Hydraulic Pile Hammer 165mm Impact Vibro Hammer
Excavator Hydraulic Pile Hammer 165mm Impact Vibro Hammer

Excavator Hydraulic Pile Hammer 165mm Impact Vibro Hammer



Product and technical parameters

Project

V-250D

V-300E

V-330E

V-350E

V-400D

V-450B

V-500A

Revolutions per minute (Rpm)

2800

3000

3000

3000

2600

2600

2600

Exciting Force (T)

43

52

56

59.6

65

75

85

Hydraulic system working pressure (Bar)

300

300

300

300

300

300

300

Hydraulic system minium flow requirements (Lpm)

175

240

270

270

280

300

320

Main machine weight (T)

1.55

2.1

2.3

3.2

3.4

3.5

3.9

Suitable for excavator weight (T)

20-24

24-30

30-35

35-40

38-42

40-45

48 above

Clip mouth weight (Kg)

C15:455 ; C16E:530 ; C18E:578 ; C30B:455 ; C35B:530

Seconday arm weight (Kg)

A200:500 ; A250B:600 ; A350:900
