Features
1. Different material such as Q345B, Q690D, Weldox and so on, are for your options or according to your appliPCion purpose.
2. We will supply all the pipeline for you, according to your appliPCion. So pls advise your appliPCion purpose (with breaker or pulverizer or with any other attachments).
3. All pins are hardened (to enhance its hardness) and high-frequency tempered (to enhance its toughness) and grinded (to enhance precision)
4. You can reuse your original bucket cylinder as the arm cylinder, the original arm cylinder as the mid-stick cylinder, the original boom cylinder as the boom cylinder. So you only need to buy one bucket cylinder from us, which saves you a lot of money.
Machinery weight | 12T | 20T | 25T | 30T | 35T | 40T | 45T |
Length | 10m | 18m | 20m | 22m | 24m | 26m | 28m |
Weight | 2.8T | 4.8T | 5.6T | 6.6T | 7.5T | 8.5T | 9.5T |
Bucket Capacity | 0.2m³ | 0.4m³ | 0.45m³ | 0.5m³ | 0.6m³ | 0.7m³ | 0.8m³ |
Maximum Digging Height | 7m | 15m | 17m | 19m | 21m | 23m | 25m |
Maximum Digging Radius | 9m | 17m | 19m | 21m | 23m | 25m | 27m |
Maximum Digging Depth | 6m | 14m | 16m | 18m | 20m | 22m | 24m |
Shipping Height | 2.2m | 3m | 3.2m | 3.2m | 3.2m | 3.4m | 3.4m |
The Largest Extended | 15m | 20m | 22m | 24m | 26m | 28m | 30m |
