1.5 cum Large Capacity Excavator Heavy Duty Bucket For Excavated Rock
Rock Bucket Data
| Capacity | 0.8 | 1 | 1.2 | 1.5 | 1.8 | 2 | 2.5 | 3 | 4 | 5 | 7 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Length | 42.5 | 46.5 | 46.5 | 51.2 | 51.2 | 53.1 | 59.1 | 66 | 67.3 | 73.6 | 82.7 |
| Width | 39.4 | 45.3 | 49.2 | 51.9 | 59.8 | 59.8 | 61 | 62.2 | 66.9 | 70.9 | 89.4 |
| High | 27.6 | 29.9 | 31.5 | 33.9 | 35.8 | 38.6 | 40.9 | 44.5 | 53.1 | 57.9 | 57.9 |
| Teeth | PC200 | PC200 | PC200 | PC300 | PC400 | PC400 | PC400 | PC650 | PC650 | PC650 | PC1000 |
| Lip | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 |
Description
Excavator Heavy Duty bucket is made of 16Mn steel, Chinese Q355b, with thicker plate and wearable parts( Bottom reinforced plates, side guard board, segments between bucket teeth. etc. ).
Features
1. Heavy duty with bottom wear plate
2. Vertical shrouds added
3. Thickening plate
4. Optional weld-on lip shrounds
