Product Details:
Payment & Shipping Terms:
|
Color: | Customer's Request | Material: | Q345B+NM400 |
---|---|---|---|
AppliPCion: | Loading/ Unloading Materials,log Load | Warranty: | 12 Months |
Type: | Rotary & Non-rotarty,Rotating Type Or Fixed Type | Size: | Customized Size |
After-sales Service Provided: | Online Support,Video Technical Support | Capacity: | 6-12M3 |
Oem: | Avaliable | Load Capacity: | 10-40t |
Product Name: | Clamshell Grab | ||
High Light: | 12M3 Hydraulic Clamshell Bucket,Q345B Clamshell Bucket,Backhoe Clam Bucket |
Hydraulic Clamshell Bucket For Excavator Backhoe Clamshell Bucket
Product Overview
The excavator shell bucket (also called grab bucket, shell bucket) is divided into two types: hydraulic swing and without hydraulic swing. The shell bucket without hydraulic rotation adopts the oil circuit of the excavator bucket cylinder, without additional hydraulic valve block and pipeline; the shell bucket with hydraulic rotation needs to add a set of hydraulic valve block and pipeline to control.
Grab Bucket Parameter
|
|||||
Model
|
|
LD1
|
LD2
|
LD3
|
LD4
|
Volume
|
M3
|
0.5
|
1
|
1.5
|
0.75
|
Type
|
|
Heavy
|
Heavy
|
Medium
|
Heavy
|
Proportion of materials
|
t/m3
|
1.2
|
1.6-2
|
1.7-1.8
|
1.2
|
Capturing the materials
|
t
|
1.3
|
1.3-1.73
|
2.1-2.3
|
1.3
|
Percentage of pulley
|
|
4
|
4
|
4
|
4
|
The diameter of steel wires
|
mm
|
9.2
|
19
|
19.5
|
9.2
|
The diameter of pulley
|
mm
|
250
|
260
|
260
|
250
|
Tons of the match hoist crane
|
t
|
3
|
5
|
5
|
3
|
Self-weight of grab
|
t
|
0.93
|
2.35
|
3.1
|
1.53
|
Total height of grab
|
mm
|
1860
|
1941
|
2720
|
2250
|
Notes
|
Design as customer’s demand
|
|
|||
Above information just for reference, detail parameter based on different lifting weight.
|
through beam is shortened,high strength,light self weight.
Company Profile
CertifiPCe &Company Experience
In 2011, the company was established
In 2014, we acquired ISO certifiPCion;
In 2015, we are one of the seven founders in Guangzhou Construction Machinery Industry Association and acquired
the title of Vice President Company;
In 2018, we acquired national high&new tech company certifiPCion and got funding from the government;
In 2019, we are one of the ten founders of China Construction Machinery Industry Association.
From 2016 to 2020, we've acquiring the title of Observing Contract and Valuing Credits Enterprise in Guangdong Province.
We earn pretty good reputation in the industry of infrastructure construction in China.
Most of the Associations that we involved in, are giving us title for being an valuable supplier.
Packaging & Shipping
2, Fast delivery time: 5-7 days for small quantity, and 20-30 days for container quantity.
3, We have a team specialized in packing and loading container, they have rich experience, and can load the max quantity products, which can help custmer save the acean freight.
FAQ
Q: HOW CAN I CHOOSE THE SUITABLE CLAMSHELL BUCKET?
A:PLEASE REFER TO BELOW QUESTIONS:
1. Brand and model of Excavator/Backhoe?
2.What's material are you going to grab?
3. Rotary type or fix type do you need?
Once you have answered the above you can easily make the correct choice.
Q: CAN THIS GRAPLE FIT A VARIETY OF MACHINES?
A: Yes, we can recommand a suitable size grapple according to your machine weight and model.
Q: WHAT CAN I GRAB?
Sand, garbage, earth, etc.
