Machine Tonnage | Description | Max.Opening ranging(in) | Weight(lbs) | Material |
6-10T | Rotating/non-rotating | 57.1 | 1430/1562 | Q690+NM360 |
11-16T | Rotating/non-rotating | 66.9 | 1760/1914 | Q690+NM360 |
17-20T | Rotating/non-rotating | 74.8 | 2134/2310 | Q690+NM360 |
21-24T | Rotating/non-rotating | 80.7 | 2354/2530 | Q690+NM360 |
25-30T | Rotating/non-rotating | 86.6 | 2640/2860 | Q690+NM360 |
31-35T | Rotating/non-rotating | 90.6 | 3080/3344 | Q690+NM360 |
36-40T | Rotating/non-rotating | 94.5 | 3630/3938 | Q690+NM360 |
41-45T | Rotating/non-rotating | 98.4 | 4268/4620 | Q690+NM360 |
65T | Rotating/non-rotating | 98.4 | 8140/9240 | Q690+NM360 |
Advantages
1. Driven by hydraulic cylinder. Every grab is driven by a separate cylinder.
2. Excavating constsruction foundation, deep hole or load soil, sand, waste. etc.
3. Excavating and loading on the limited space. (Usualaly work with telescopic boom)
Features
1.Special steel material with high ductility and high resistance
2.Imported balance valve motor with buffering and braking kinetic energy.
3.The cylinder is equipped with non-return valve, more safety for grabbing
4.High strength rotating support device, the operator can manipulates the swinging speed and its rotating direction for 360 degree clockwise and anticlockwise.
5.With the biggest open width of the same level product. Best performance with minimum weight. Special customized big cylinder. Capable of grabbing heavier stuff.
