HMB850 Top Type 15ton Excavator Hydraulic Hammer for Komatsu
SpecifiPCion
|
HYDRAULIC BREAKER SPECIFIPCIONS
|
||||||||
|
HMB Model
|
Operating Weight (kg)
|
Required Oil Flow (L/Min)
|
Working Pressure (Bar)
|
Impact Rate (Bpm)
|
Chisel Diameter (mm)
|
Hose Diameter (inch)
|
Carrier weight (ton)
|
Valve Ass'y Position (/)
|
|
HMB680
|
340
|
36-60
|
110-140
|
500-900
|
68
|
1/2
|
3-7
|
Internal
|
|
HMB750
|
480
|
50-90
|
120-170
|
400-800
|
75
|
1/2
|
6-9
|
Internal
|
|
HMB850
|
580
|
45-85
|
127-147
|
400-800
|
75
|
3/4
|
7-14
|
Internal
|
|
HMB1000
|
950
|
80-120
|
150-170
|
400-650
|
100
|
3/4
|
10-15
|
Internal
|
|
HMB1350
|
1650
|
130-170
|
160-185
|
400-650
|
135
|
1
|
18-25
|
Internal
|
|
HMB1400
|
2000
|
150-190
|
165-195
|
400-800
|
140
|
1
|
20-30
|
Internal
|
|
HMB1550
|
2900
|
150-230
|
170-200
|
400-800
|
155
|
1
|
27-36
|
Internal
|
Product Advantages
1. Selected raw material - high quality heavy duty wear resistant steel.
