15-20 Tons Excavator Tilt Bucket With Two Cylinder For PC150 PC160 PC200
Production Descrption
Huitong ExcavatorTilting bucket designed with double cylinders and with double cutting edges. The space of bolts in cutting edges are 6 inch, which is the standard cutting edges for you can find spare cutting edges in local easily. Two heavy-duty hydraulic cylinders with hardened rods for excellent holding power.(tilt cylinder with the protector)
And our tilting bucket also designed with double cylinders and with double cutting edges( Single cylinder design is also available). The space of bolts in cutting edges are 6 inch, which is the standard cutting edges for you can find spare cutting edges in local easily. Cutting edge and side cutters are 400 HB steel. Robust, wear-resistant blades and side cutters. Good Plane properties by smooth, stable base of 400 HB steel
Characteristic
|
Model
|
HT 50
|
HT 80
|
HT 120
|
HT 200
|
HT 00
|
|
Pin Diameter(mm)
|
45
|
50
|
60/65
|
80
|
90/100
|
|
Ears Distance(mm)
|
170
|
220
|
260
|
340
|
390
|
|
Pin to Pin Center(mm)
|
245
|
310
|
360
|
465
|
530
|
|
Dimensions(mm)
|
1200*788*916
|
1400*869*1008
|
1700*1074*1210
|
1900*1195*1478
|
2030*1362*1729
|
|
Apply to(ton)
|
5
|
6-8
|
12-18
|
20-24
|
25-36
|
Production Details
