Soosan SB40 Hydraulic Rock Breaker With 68mm Chisel For Excavator
Hydraulic Breaker SpecifiPCion
|
Model
|
Unit
|
Small range
|
Medium range
|
||||
|
Operating Weight
(side/top/box)
|
kg
|
70/72/102
|
95/95/126
|
138/138/152
|
180/180/224
|
263/263/299
|
334/335/375
|
|
Length(side/top/box)
|
mm
|
910/1086/1190
|
1090/1235/1331
|
1178/1344/1417
|
1239/1460/1472
|
1373/1684/1660
|
1515/1706/1712
|
|
Working Flow Rate
|
1iter/min
|
15-25
|
20-30
|
25-50
|
30-60
|
40-70
|
50-90
|
|
Oil Relief Pressure
|
kg/cm^2
|
160
|
160
|
160
|
160
|
170
|
170
|
|
Working Pressure
|
kg/cm^2
|
90-120
|
90-120
|
90-120
|
100-130
|
110-140
|
120-170
|
|
Impact Rate
|
bpm
|
800-1400
|
700-1200
|
600-1000
|
500-1000
|
500-900
|
400-800
|
|
Chisel Diameter
|
mm
|
￠40
|
￠45
|
￠53
|
￠60
|
￠68
|
￠75
|
|
Oil Pipe Nominal Diameter
|
inch
|
1/2
|
1/2
|
1/2
|
1/2
|
1/2
|
‘1/2
|
|
Back Head Pressure
|
kg/cm^2
|
16
|
16
|
16
|
16
|
16
|
16±0.5
|
|
Accumulator Pressure
|
kg/cm^2
|
/
|
/
|
/
|
/
|
/
|
/
|
|
Applicable Excavator Weight
|
ton
|
0.8-2.5
|
1.2-3.0
|
2.5-4.5
|
3-5.5
|
4-7
|
6-9
|
|
Applicable Bucket
|
m^3
|
0.07
|
0.03-0.1
|
0.06-0.2
|
0.06-0.2
|
0.15-0.25
|
0.2-0.4
|
Features
Mining------------Mining,Second-time breaking
Metallurgy-------Clearing slag,Demolition of furnace and foundation
Road------------- Repairing,Breaking,Foundation work
Railway----------Tunneling,Demolition of bridge
Construction----Demolition of building and reinforced concrete
Ship repairing--Clearing clam and rust from the hull
Others----------- Breaking frozen mud
