Soosan SB30 SB40 SB50 SB81 Excavator Hydraulic Breaker For Construction
Hydraulic Breaker SpecifiPCion
Model | Unit | Small range | Medium range | ||||
Operating Weight (side/top/box) | kg | 70/72/102 | 95/95/126 | 138/138/152 | 180/180/224 | 263/263/299 | 334/335/375 |
Length(side/top/box) | mm | 910/1086/1190 | 1090/1235/1331 | 1178/1344/1417 | 1239/1460/1472 | 1373/1684/1660 | 1515/1706/1712 |
Working Flow Rate | 1iter/min | 15-25 | 20-30 | 25-50 | 30-60 | 40-70 | 50-90 |
Oil Relief Pressure | kg/cm^2 | 160 | 160 | 160 | 160 | 170 | 170 |
Working Pressure | kg/cm^2 | 90-120 | 90-120 | 90-120 | 100-130 | 110-140 | 120-170 |
Impact Rate | bpm | 800-1400 | 700-1200 | 600-1000 | 500-1000 | 500-900 | 400-800 |
Chisel Diameter | mm | 40 | 45 | 53 | 60 | 68 | 75 |
Back Head Pressure | kg/cm^2 | 16 | 16 | 16 | 16 | 16 | 16±0.5 |
Applicable Excavator Weight | ton | 0.8-2.5 | 1.2-3.0 | 2.5-4.5 | 3-5.5 | 4-7 | 6-9 |
Applicable Bucket | m^3 | 0.07 | 0.03-0.1 | 0.06-0.2 | 0.06-0.2 | 0.15-0.25 | 0.2-0.4 |
Advantages
1. Material: 20CrMo, including front head, cylinder, back head.
