20-25 Ton Excavator Mounted Vibratory Hammer Sheet Pile Hammer

20-25 Ton Excavator Mounted Vibratory Hammer Sheet Pile Hammer
20-25 Ton Excavator Mounted Vibratory Hammer Sheet Pile Hammer
video play

Large Image :  20-25 Ton Excavator Mounted Vibratory Hammer Sheet Pile Hammer

Product Details:
Place of Origin: China
Brand Name: HUITONG
Model Number: komatsu/kobelco/hitachi/PC/hyundai/Volvo
Payment & Shipping Terms:
Minimum Order Quantity: 1 PCS/SET
Price: USD12000-18000/SET
Delivery Time: 7-15 work days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 200SET per month
Detailed Product Description
Product Name: Excavator Hydraulic Vibratory Hammer AppliPCion: Building Foundation,Pile Driving
Color: Yellow/Blue/ Customer's Requirement Weight: 1.3T-3.5T
Piling Speed(m/min): 1-6m/min MOQ: 1 PCS
After-sales Service Provided: Video Technical Support
High Light:

25 Ton Excavator Mounted Vibratory Hammer

,

Excavator Mounted Vibratory Hammer

,

Excavator Sheet Pile Hammer

20-25Ton Excavator Mounted Vibratory Hammer Excavator Sheet Pile Hammer

20-25 Ton Excavator Mounted Vibratory Hammer Sheet Pile Hammer

Excavator Pile Hammer

Huitong Hydraulic Pile Hammers , also goes by Pile Driving Hammer, Vibro Hammer, are widely used in many big projects, suitable for all model of excavator.

Hydraulic pile driver is using its high frequency vibration to vibrate pile body with high acceleration to pass the vertical vibration of mechanical produce to pile which leading to changes in the soil structure around the pile, strength decrease. Soil around the piles become liquefaction to reduce frictional resistance between side of the pile and the soil. Then using the excavator down force, vibrating pile hammer and pile body weight to sink pile into the soil. When extracting piles, in the condition of vibration to pull out the pile by using excavator lift force. Excitation force needed by pile driving machinery are comprehensive determined by site soil, soil condition, moisture content and type of pile, construction.

AppliPCion: cast-in-place concrete pile, precast concrete pile, concrete expanded bore pile, lime pile, stone column. Beside, it's widely used in  trestle work, cofferdam,offshore working platform, and also group pile or wind mill single pile
20-25 Ton Excavator Mounted Vibratory Hammer Sheet Pile Hammer 20-25 Ton Excavator Mounted Vibratory Hammer Sheet Pile Hammer

20-25 Ton Excavator Mounted Vibratory Hammer Sheet Pile Hammer 20-25 Ton Excavator Mounted Vibratory Hammer Sheet Pile Hammer 20-25 Ton Excavator Mounted Vibratory Hammer Sheet Pile Hammer

20-25 Ton Excavator Mounted Vibratory Hammer Sheet Pile Hammer
20-25 Ton Excavator Mounted Vibratory Hammer Sheet Pile Hammer

20-25 Ton Excavator Mounted Vibratory Hammer Sheet Pile Hammer



Product and technical parameters

Project

V-250D

V-300E

V-330E

V-350E

V-400D

V-450B

V-500A

Revolutions per minute (Rpm)

2800

3000

3000

3000

2600

2600

2600

Exciting Force (T)

43

52

56

59.6

65

75

85

Hydraulic system working pressure (Bar)

300

300

300

300

300

300

300

Hydraulic system minium flow requirements (Lpm)

175

240

270

270

280

300

320

Main machine weight (T)

1.55

2.1

2.3

3.2

3.4

3.5

3.9

Suitable for excavator weight (T)

20-24

24-30

30-35

35-40

38-42

40-45

48 above

Clip mouth weight (Kg)

C15:455 ; C16E:530 ; C18E:578 ; C30B:455 ; C35B:530

Seconday arm weight (Kg)

A200:500 ; A250B:600 ; A350:900
