Reliable Quality Excavator Hydraulic Pile Hammer Customization Vibratory Hammer
Huitong Hydraulic Pile Hammers , also go by Vibro Hammer, Pile Driving Hammer.
Advantages:
1. In the general piling wokr, it is faster than other system.
2. It saves time in the pile driving or pile pulling.
3. We adopt rubber pad to reduce noise and vibration on the outside.
4. The hydraulic oil motor is small in size and light, but generates high drive power and speed.
5. With the use of changeable pump, you may properly revision the vibration frequency.
| RPM | 2800 | 3000 | 3000 | 3000 | 2600 | 2600 | 2600 |
| Exciting Force (T) | 39.5 | 48 | 51 | 53.4 | 55.5 | 58 | 63 |
| Hydraulic system working pressure (Bar) | 300 | 300 | 300 | 300 | 300 | 300 | 300 |
| Hydraulic system Minium flow requirements(Lpm) | 175 | 240 | 270 | 270 | 280 | 300 | 320 |
| Main machine weight (T) | 1.55 | 1.65 | 1.65 | 1.8 | 2.0 | 2.05 | 2.1 |
| Suitable for excavator weight (T) | 20-24 | 24-30 | 30-35 | 38-42 | 35-40 | 40-45 | 48above |
| Clip mouth weight (KG) | C15:455 | C16E:530 | C18E:578 | C30B:455 | C35B:530 | - | - |
| Seconday arm weight (KG) | A200:500kg | A250B:600KG | A350:900KG | - | - | - | - |
