Features
1) Use high-strength material ; suitable for various models of 4-45 tons.
2) Use the safety device of the hydraulic control check valve to ensure safety, convenient operation and improve work efficiency.
3) The excavator configuration parts can be replaced without modifiPCion or disassembly of the pin shaft, so the installation is quick and the work efficiency can be greatly improved.
4) Only takes ten seconds to attach the quick hitch to your machine.
| Model |
Carrier Weight |
Pin Diameter |
Arm Width |
Pin Center Distance |
Cylinder Scalling Distance |
Pressure |
Oil Flow |
Weight
|
| Ton | mm | mm | mm | mm | kg/cm2 | L/min | kg | |
| HT02 | 4-6 | 45-50 | 155-170 | 230-270 | 205-270 | 40-380 | 10-20 | 50-60 |
| HT4 | 5-9 | 50-55 | 180-200 | 290-360 | 340-450 | 40-380 | 10-20 | 80-90 |
| HT06 | 9-19 | 60-70 | 232-315 | 380-420 | 340-486 | 40-380 | 10-20 | 120-130 |
| HT08 | 17-23 | 70-80 | 306-340 | 460-480 | 256-590 | 40-380 | 10-20 | 280-290 |
| HT10 | 23-35 | 80-90 | 325-350 | 473-540 | 413-590 | 40-380 | 10-20 | 450-530 |
| HT17 | 33-45 | 90-120 | 416-469 | 550-620 | 520-590 | 40-380 | 10-20 | 450-580 |
| HT-mini | 1.5-4 | 25-40 | 80-140 | 80-150 | 170-206 | 40-380 | 10-20 | 25-30 |
