Machine Weight (lbs)
|
Main plate thickness (in)
|
Weight (lbs)
|
Teeth (Optional)
|
Material
|
|
13220-22040
|
2.4
|
837
|
PC100
|
Q355B
|
|
24250-35270
|
3.1
|
1190
|
PC200
|
Q355B
|
|
37470-44090
|
3.9
|
1499
|
PC300
|
Q355B
|
|
46290-52910
|
3.9
|
1587
|
PC300
|
Q355B/Q460/NM360
|
|
55110-66130
|
3.9
|
1719
|
PC400
|
Q355B/NM360
|
|
68340-77160
|
3.9
|
1807
|
PC400
|
Q355B/Hardox500
|
Product Features
A. Made of high strength steel plate, easy to install, easy to use.
B. Installed with high strength ripper teeth, strong digging capacity;
C. Convenient for digging and loading at the same time, high efficiency.
D. Suitable for shoving hard substances such as hard rocks, frozen ground, stone and weathered granite to facilitate later operation.
Description
1. Our products are made of high strength steel Q355.
2. The quality of our products is stable, and the noise and vibration are very small.
3. The product is easy to maintain and install.
4. It can be deeply customized according to the requirements of customers to meet the requirements of all aspects of actual
production.
5. The product is used for breaking frozen soil, ice surface, turning soil and other appliPCions.
6.The bucket teeth of the front end can be replaced to extend the service life of the product.
